带气囊航行体下落入水冲击过程数值模拟

段金雄; 陆德顺; 林威; 孙铁志

doi:10.11883/bzycj-2023-0170

带气囊航行体下落入水冲击过程数值模拟

doi: 10.11883/bzycj-2023-0170

大连理工大学，船舶工程学院，工业装备结构分析优化与CAE软件全国重点实验室，辽宁大连 116024

基金项目: 国家自然科学基金面上项目(52071062)

详细信息

作者简介:
段金雄（1998－　），男，硕士研究生，ychdjx2536843982@163.com

通讯作者:
孙铁志（1986－　），男，博士，教授，suntiezhi@dlut.edu.cn

中图分类号: O
计量
- 文章访问数: 55
- HTML全文浏览量: 4
- PDF下载量: 41
- 被引次数: 0
出版历程
- 收稿日期: 2023-01-01
- 网络出版日期: 2023-09-12

Numerical simulation on water entry impact process of the vehicle with airbags

State Key Laboratory of Structural Analysis and Optimization for Industrial Equipment and CAE Software, School of Naval Architecture, Dalian University of Technology, Dalian 116024, Liaoning, China

摘要

摘要: 为探究带气囊航行体下落入水过程中的运动演化过程以及载荷作用特性，基于VOF（Volume of Fluid）多相流模型和k-ω SST湍流模型，开展了带气囊航行体倾斜下落入水冲击过程的数值模拟。通过将数值计算得到的水平圆柱入水过程空泡形态以及下落位移与试验结果进行对比，验证了所采用的数值方法的适用性与准确性，并分析了带气囊航行体倾斜下落入水过程中航行体的运动演化过程以及载荷作用特性。结果表明，航行体下落入水过程分为了冲击入水阶段与升沉衰减阶段，其中航行体尾部砰击，气囊砰击以及气囊加速展开等过程均会形成局部冲击加速度峰值，并且气囊加速展开砰击水体造成的加速度峰值最大；其次，气囊冲击入水过程中的气囊冲击受力会导致气囊与航行体之间的设计连杆出现较大的拉力峰值；最后，入水空泡溃灭载荷会造成航行体局部压力波动，极大影响航行体的入水姿态变化。综合分析认为气囊装置可以为航行体下落入水提供较好的缓冲保护，计算所得到的带气囊航行体下落冲击响应数据可以为航行体缓冲回收装置设计提供参考依据。
- 航行体入水 /
- 入水冲击 /
- 缓冲气囊 /
- 砰击载荷
Abstract: To investigate the motion evolution process and load action characteristics of a vehicle with airbags falling into water, based on the VOF (Volume of Fluid) multiphase flow model and the k-ω SST turbulence model, the numerical simulation of the inclined falling water impact process of a vehicle with airbags was conducted. The applicability and accuracy of the numerical method were verified by comparing the water entry cavity shape and falling displacement obtained from numerical calculations during the horizontal cylinder’s water entry process with experimental results. The motion evolution process and load action characteristics of a vehicle with airbags during the inclined falling into water process were analyzed. The results show that the process of the vehicle falling into the water is divided into two stages: the impact into the water stage and the heave attenuation stage. Among them, the tail attack of the vehicle, the airbags attack, and the airbags acceleration deployment process all form local peak impact acceleration, and the acceleration peak caused by the airbag acceleration deployment attacking the water body is the highest. The impact force of the airbags will cause a significant tensile peak in the design connecting rod between the airbags and the vehicle during the process of airbag impact entering the water. The collapse load of the water entry cavity will cause local pressure fluctuations of the vehicle, greatly affecting the changes in the vehicle’s water entry attitude. In general, the airbag device can provide good buffering protection for the vehicle falling into water, and the calculated impact response data of the vehicle with airbags can provide a reference for the design of the vehicle's buffer recovery device.
- vehicle entering water /
- water entry impact /
- buffer airbags /
- slamming load

HTML全文

图 1 水平圆柱入水空泡形态试验与数值结果对比

Figure 1. Comparison of experimental and numerical results of horizontal cylinder water-entry cavity shape

下载: 全尺寸图片幻灯片

图 2 水平圆柱下落过程质心位置时历曲线对比

Figure 2. Comparison of the time history curve of horizontal cylinder’s centroid position during falling process

下载: 全尺寸图片幻灯片

图 3 计算模型具体设计与尺寸

Figure 3. Computational model specific design and size

下载: 全尺寸图片幻灯片

图 4 计算域尺寸及其设置

Figure 4. Computing domains size and settings

下载: 全尺寸图片幻灯片

图 5 计算域网格

Figure 5. Mesh of computing domains

下载: 全尺寸图片幻灯片

图 6 航行体初始下落位置

Figure 6. Initial drop position of vehicle

下载: 全尺寸图片幻灯片

图 7 气囊转动角度时历曲线

Figure 7. Time history curve of rotation angle of airbag

下载: 全尺寸图片幻灯片

图 8 航行体下落过程

Figure 8. The process of vehicle falling

下载: 全尺寸图片幻灯片

图 9 航行体垂直位移时历曲线

Figure 9. Vertical displacement time history curve of vehicle

下载: 全尺寸图片幻灯片

图 10 航行体垂直速度时历曲线

Figure 10. Vertical velocity time history curve of vehicle

下载: 全尺寸图片幻灯片

图 11 航行体水平位移时历曲线

Figure 11. Horizontal displacement time history curve of vehicle

下载: 全尺寸图片幻灯片

图 12 航行体俯仰角度时历曲线

Figure 12. Pitch angle time history curve of vehicle

下载: 全尺寸图片幻灯片

图 13 航行体垂直受力时历曲线

Figure 13. Vertical force time history curve of vehicle

下载: 全尺寸图片幻灯片

图 14 航行体水平受力时历曲线

Figure 14. Horizontal force time history curve of vehicle

下载: 全尺寸图片幻灯片

图 15 航行体入水空泡演化过程

Figure 15. Evolution of water-entry cavity of vehicle

下载: 全尺寸图片幻灯片

图 16 航行体俯仰力矩时历曲线

Figure 16. Pitching moment time history curve of vehicle

下载: 全尺寸图片幻灯片

图 17 气囊受力时历曲线

Figure 17. Force time history curves of airbags

下载: 全尺寸图片幻灯片

图 18 气囊a表面压力等值线分布

Figure 18. Surface pressure contour distribution of airbag a

下载: 全尺寸图片幻灯片

图 19 气囊a表面压力分布雷达图

Figure 19. Surface pressure distribution radar map of airbag a

下载: 全尺寸图片幻灯片

图 20 压力监测点位置分布

Figure 20. Location distribution of pressure monitoring points

下载: 全尺寸图片幻灯片

图 21 流场压力演化云图

Figure 21. Flow field pressure evolution contour

下载: 全尺寸图片幻灯片

图 22 顶部监测点压强变化曲线

Figure 22. Pressure change curve at the top monitoring point

下载: 全尺寸图片幻灯片

图 23 底部监测点压强变化曲线

Figure 23. Pressure change curve at the bottom monitoring point

下载: 全尺寸图片幻灯片

图 24 侧流端监测点压强变化曲线

Figure 24. Pressure change curve at the side flow end monitoring points

下载: 全尺寸图片幻灯片

图 25 低压空泡气团的发展过程

Figure 25. The development process of low pressure cavitation air mass

下载: 全尺寸图片幻灯片

图 26 迎流端监测点压强曲线

Figure 26. Pressure curve at upstream end monitoring points

下载: 全尺寸图片幻灯片

图 27 背流端监测点压强曲线

Figure 27. Pressure curve at backflow end monitoring points

下载: 全尺寸图片幻灯片

参考文献(21)

[1]	杨继峰, 刘丙杰, 陈捷, 等. 潜射弹道导弹水下大深度发射技术途径分析 [J]. 兵器装备工程学报, 2020, 41(06): 32–36. DOI: 10.11809/bqzbgcxb2020.06.007. YANG J F, LIU B J, CHEN J, et al. Research on underwater large depth launching technology of submarine launched ballistic missile [J]. Journal of Ordnance Equipment Engineering, 2020, 41(06): 32–36. DOI: 10.11809/bqzbgcxb2020.06.007.
[2]	王一伟, 黄晨光. 高速航行体水下发射水动力学研究进展 [J]. 力学进展, 2018, 48(00): 259–298. DOI: 10.6052/1000-0992-16-020. WANG Y W, HUANG C G. Research progress on hydrodynamics of high speed vehicles in the underwater launching progress [J]. Advances in Mechanics, 2018, 48(00): 259–298. DOI: 10.6052/1000-0992-16-020.
[3]	包健, 马贵辉, 孙龙泉, 等. 带椭球形气囊航行体落水-上浮过程仿真 [J]. 兵工学报, 2023, 1–14. BAO J, MA G H, SUN L Q, et al. Simulation of falling-floating process of vehicle with ellipsoidal airbags [J]. Acta Armamentarii, 2023: 1–14.
[4]	陈洋, 吴亮, 曾国伟, 等. 带环形密闭气囊弹体入水冲击过程的数值分析 [J]. 爆炸与冲击, 2018, 38(05): 1155–1164. DOI: 10.11883/bzycj-2017-0387. CHEN Y, WU L, ZHEN G W, et al. Numerical analysis of the water entry process of a projectile with a circular airbag [J]. Explosion and Shock Waves, 2018, 38(05): 1155–1164. DOI: 10.11883/bzycj-2017-0387.
[5]	林赓. 气囊结构落水砰击瞬态流固耦合特性研究 [D]. 哈尔滨: 哈尔滨工程大学, 2016.
[6]	陈开颜, 陈辉, 魏海鹏, 等. 带囊回转体落水仿真与试验研究 [J]. 船舶力学, 2022, 26(03): 315–322. DOI: 10.3969/j.issn.1007-7294.2022.03.001. CHEN K Y, CHEN H, WEI H P, et al. Simulation and experimental study on a cylinder with airbags falling into water [J]. Journal of Ship Mechanics, 2022, 26(03): 315–322. DOI: 10.3969/j.issn.1007-7294.2022.03.001.
[7]	JIANG Y Y, TANG W Y. Numerical investigation on water entry of a three-dimensional flexible bag of an air cushion vehicle [J]. Ocean Engineering, 2022, 247(1–3): 110653. DOI: 10.1016/j.oceaneng.2022.110653.
[8]	DANG H X, ZHANG X G, LI B, et al. Multi-disciplinary co-simulation of floating process induced by pneumatic inflatable collar for underwater vehicle recovery [J]. Ocean Engineering, 2020, 216(6): 108008. DOI: 10.1016/j.oceaneng.2020.108008.
[9]	ZHAO R, FALTINSEN O. Water entry of two-dimensional bodies [J]. Journal of Fluid Mechanics, 1993, 246: 593–612. DOI: 10.1017/S002211209300028X.
[10]	CHAUDHRY A Z, SHI Y, PAN G. Recent developments on the water entry impact of wedges and projectiles [J]. Ships and Offshore Structures, 2020, 17(3): 1–20. DOI: 10.1080/17445302.2020.1835053.
[11]	王永虎, 石秀华. 入水冲击问题研究的现状与进展 [J]. 爆炸与冲击, 2008, 28(3): 276–282. DOI: 10.11883/1001-1455(2008)03-0276-07. WANG Y H, SHI X H. Review on research and development of water-entry impact problem [J]. Explosion and Shock Waves, 2008, 28(3): 276–282. DOI: 10.11883/1001-1455(2008)03-0276-07.
[12]	黄志刚, 孙铁志, 杨碧野, 等. 平头锥型回转体高速入水结构强度数值分析 [J]. 爆炸与冲击, 2019, 39(4): 043201. DOI: 10.11883/bzycj-2017-0330. HUANG Z G, SUN T Z, YANG B Y, et al. Numerical analysis on structural strength of a cone-shaped flatted revolution body during high-speed water-entry [J]. Explosion and Shock Waves, 2019, 39(4): 043201. DOI: 10.11883/bzycj-2017-0330.
[13]	王世晟, 鲍文春, 韩敬永, 等. 回转体头部通气入水流场演化与载荷特性数值预报研究 [J]. 爆炸与冲击, 2022, 42(05): 52–62. DOI: 10.11883/bzycj-2021-0494. WANG S S, BAO W C, HAN J Y, et al. Numerical study on the flow field and load characteristics of a head-ventilated revolving body during water entry [J]. Explosion and Shock Waves, 2022, 42(05): 52–62. DOI: 10.11883/bzycj-2021-0494.
[14]	TRUSCOTT T T, EPPS B P, BELDEN J. Water Entry of Projectiles [J]. Annual Review of Fluid Mechanics, 2014, 46: 255–378. DOI: 10.1146/annurev-fluid-011212-140753.
[15]	DU Y, WANG Z Y, WANG Y W, et al. Study on the cavity dynamics of water entry for horizontal objects with different geometrical shapes [J]. Ocean Engineering, 2022, 252(6): 111242. DOI: 10.1016/j.oceaneng.2022.111242.
[16]	SUN Y T, LI S, MING F R, et al. An experimental study of the water entry trajectories of truncated cone projectiles: The influence of nose parameters [J]. Physics of Fluids, 2022, 34(5): 052102. DOI: 10.1063/5.0089366.
[17]	SHI W K, SHEN Y M, CHEN J Q, et al. SPH simulations on water entry characteristics of a re-entry capsule [J]. Engineering Analysis with Boundary Elements, 2020, 119(4): 257–268. DOI: 10.1016/j.enganabound.2020.07.018.
[18]	YU P Y, XIE H, LIU F, et al. Numerical investigation on the water entry of a 2D seaplane section with heel angles [J]. Ocean Engineering, 2022, 262(2): 112236. DOI: 10.1016/j.oceaneng.2022.112236.
[19]	高英杰, 孙铁志, 张桂勇, 等. 回转体高速倾斜入水的流场特性及结构响应 [J]. 爆炸与冲击, 2020, 40(12): 101–113. DOI: 10.11883/bzycj-2020-0014. GAO Y J, SUN T Z, ZHANG G Y, et al. Flow characteristics and structure response of high-speed oblique water-entry for a revolution body [J]. Explosion and Shock Waves, 2020, 40(12): 101–113. DOI: 10.11883/bzycj-2020-0014.
[20]	Plesset M. The dynamics of cavitation bubbles [J]. Journal of Applied Mechanics, 1949, 16: 277–282. DOI: 10.1007/BF02120348.
[21]	Wei Z Y, Hu C H. An experimental study on water entry of horizontal cylinders [J]. Journal of Marine Science & Technology, 2014, 19(3): 338–350. DOI: 10.1007/s00773-013-0252-z.
