Experiments for thermomechanical effects based on Z-pinch X-ray sources
-
摘要: 材料或结构对强脉冲X射线的响应如热激波的传播和喷射冲量等，统称为X射线热-力学效应，在抗辐射加固研究、天体物理、行星科学等领域具有重要应用。利用驱动电流近10 MA脉冲功率装置上的丝阵Z箍缩X射线源开展了初步的热-力学效应实验。采用20 mm直径的双层铝丝阵产生了约230 kJ的X射线总辐射能，其中铝的K壳层产额约为30 kJ，距离源中心5 cm处的样品上的X射线能注量为732 J/cm2。受辐照样品为厚度2 mm、直径10 mm的铝制圆盘，其背面设置有铝衬套，样品与衬套的总质量为585 mg。采用全光纤光子多普勒测速（PDV）系统来测量受辐照样品后表面的运动过程。PDV测量的样品后表面速度历程显示，当热激波到达后表面时的自由面速度为2.12 km/s，样品最终的整体运动速度为180 m/s。根据冲击波关系式以及动量守恒原理，推导出X射线在样品中产生的热激波应力为19.2 GPa，单位面积上的喷射冲量为1341 Pa·s，进而由喷射冲量和X射线能注量测量结果可以推出冲量耦合系数为1.83 Pa·s·cm2/J。同时，对实验测量结果的可靠性和不确定度进行了讨论和分析。这些实验结果初步验证了将PDV技术应用于热-力学效应研究的可行性。Abstract: Responses of materials and structures to intense pulsed X-ray radiation, such as thermal shock wave propagation and blowoff impulse generation are referred to collectively as X-ray thermomechanical effects, which have been applied to radiation hardening, astrophysics, and planetary science. Preliminary experiments for thermomechanical effects have been performed utilizing wire array Z-pinch X-ray sources on a pulsed power facility with a drive current of about 10 MA. A total X-ray radiation energy of about 230 kJ was produced by a nested aluminum wire array of 20 mm in outer diameter, and theK-shell yield of about 30 kJ for aluminum was measured. An X-ray energy fluence up to 732 J/cm2 was produced on an irradiated target which was positioned at 5 cm away from the X-ray source center. The irradiated target was an aluminum disk 2 mm in thickness and 10 mm in diameter, backed by an aluminum liner. The total weight of the disk and liner was 585 mg. An all-fiber photonic Doppler velocimeter (PDV) was used to monitor the motion of the rear surface of the irradiated target. The velocity history measured by PDV suggested a free-face velocity of 2.12 km/s when the shock wave arrived at the rear surface of the target, and the final velocity of the target is 180 m/s. Based on the Hugoniot relationships and the law of momentum conservation, a stress of the thermal shock wave of 19.2 GPa and a blowoff impulse per unit target area of 1341 Pa·s were deduced. Furthermore, a consequent coupling coefficient of 1.83 Pa·s·cm2/J was estimated from the measurements of blowoff impulse and the X-ray energy fluence. Finally, discussions on the reliability and uncertainty of the measurement were presented. These experimental results described here preliminarily validated the feasibility of the application of PDV to the research of X-ray thermomechanical effect.
-
图 2 双层铝丝阵典型实验结果（Shot 477）
Figure 2. Typical results from the nested Al wire array experiment (Shot 477)
图 3 典型铝丝阵X射线分幅图像和K壳层辐射谱
Figure 3. Typical X-ray framing images and K-shell emission spectrum from the Al wire array experiment
-
[1] 周南. 脉冲辐照热激波与压缩应力波 [J]. 高压物理学报, 1994, 8(3): 190–199. DOI: 10.11858/gywlxb.1994.03.006.ZHOU N. The thermal shock wave induced by X-ray and electron beam radiation and compressive stress wave [J]. Chinese Journal of High Pressure Physics, 1994, 8(3): 190–199. DOI: 10.11858/gywlxb.1994.03.006. [2] 汤文辉, 张若棋, 赵国民. 脉冲X射线诱导的热击波 [J]. 高压物理学报, 1995, 9(2): 107–111. DOI: 10.11858/gywlxb.1995.02.004.TANG W H, ZHANG R Q, ZHAO G M. Thermal shock wave induced by impulsive X-ray [J]. Chinese Journal of High Pressure Physics, 1995, 9(2): 107–111. DOI: 10.11858/gywlxb.1995.02.004. [3] LANGLEY R W. Analytical relationships for estimating the effects of X-rays on materials: AFRPL-TR-74-52 [R]. USA: AFRPL, 1974. [4] 彭常贤, 刘晋, 胡泽根, 等. 强脉冲X光辐照硬铝靶产生喷射冲量的研究 [J]. 强激光与粒子束, 1998, 10(3): 383–386.PENG C X, LIU J, HU Z G, et al. Studies of the blowoff impulses in the aluminum alloy targets irradiated by intense soft X-ray [J]. High Power Laser and Particle Beams, 1998, 10(3): 383–386. [5] 彭常贤, 谭红梅, 林鹏, 等. 脉冲软X光辐射三种材料的喷射冲量实验研究 [J]. 强激光与粒子束, 2003, 15(1): 89–93.PENG C X, TAN H M, LIN P, et al. Experimental studies of blowoff impulse in materials irradiated by pulsed soft X-ray [J]. High Power Laser and Particle Beams, 2003, 15(1): 89–93. [6] 张永民. 电子束热力学效应研究的关键技术分析 [J]. 现代应用物理, 2010, 1(4): 380–386.ZHANG Y M. Key technologies for study on thermal mechanical effects of electron beams [J]. Modern Applied Physics, 2010, 1(4): 380–386. [7] REMO J L, FURNISH M D, LAWRENCE R J. Plasma-driven Z-pinch X-ray loading and momentum coupling in meteorite and planetary materials [J]. Journal of Plasma Physics, 2013, 79(2): 121–141. DOI: 10.1017/S0022377812000712. [8] 毛勇建, 邓宏见, 何荣建. 强脉冲软X光喷射冲量的几种模拟加载技术 [J]. 强度与环境, 2003, 30(2): 55–64. DOI: 10.3969/j.issn.1006-3919.2003.02.008.MAO Y J, DENG R J, HE Y J. Several simulation techniques of blow-off impulse by intense pulsed cold X-rays [J]. Structure and Environment Engineering, 2003, 30(2): 55–64. DOI: 10.3969/j.issn.1006-3919.2003.02.008. [9] 赵国民, 张若棋, 陈刚, 等. 铅壳柔爆索爆炸特性实验研究 [J]. 高压物理学报, 2001, 15(2): 91–96. DOI: 10.11858/gywlxb.2001.02.003.ZHAO G M, ZHANG R Q, CHEN G, et al. Investigations of explosion characteristics of lead shield mild detonating fuse [J]. Chinese Journal of High Pressure Physics, 2001, 15(2): 91–96. DOI: 10.11858/gywlxb.2001.02.003. [10] 彭常贤, 王占江, 王伟. “闪光二号”电子束辐照平板靶产生热击波的实验研究 [J]. 高压物理学报, 1995, 9(1): 20–28. DOI: 10.11858/gywlxb.1995.01.004.PENG C X, WANG Z J, WANG W. Experimental studies of the thermal shock wave produced in the flat plate targets bombarded by electron beam on FLASH-Ⅱ [J]. Chinese Journal of High Pressure Physics, 1995, 9(1): 20–28. DOI: 10.11858/gywlxb.1995.01.004. [11] 彭常贤, 林鹏, 谭红梅, 等. PVDF在电子束辐射材料产生的热激波测量中的应用 [J]. 高压物理学报, 2002, 16(1): 7–15. DOI: 10.11858/gywlxb.2002.01.002.PENG C X, LIN P, TAN H M, et al. Application of PVDF for thermal shock wave measurement in materials radiated by electron beam [J]. Chinese Journal of High Pressure Physics, 2002, 16(1): 7–15. DOI: 10.11858/gywlxb.2002.01.002. [12] SPIELMAN R B, DEENEY C, CHANDLER G A, et al. Tungsten wire-array Z-pinch experiments at 200 TW and 2 MJ [J]. Physics of Plasmas, 1998, 5(5): 2105–2111. DOI: 10.1063/1.872881. [13] 林鹏, 王等旺, 陈博. 脉冲软X射线汽化喷射冲量 [J]. 爆炸与冲击, 2013, 33(S1): 111–115.LIN P, WANG D W, CHEN B. Vaporized blow-off impulse induced by pulse soft X-ray [J]. Explosion and Shock Waves, 2013, 33(S1): 111–115. [14] DENG J J, XIE W P, FENG S P, et al. Initial performance of the primary test stand [J]. IEEE Transactions on Plasma Science, 2013, 41(10): 2580–2583. DOI: 10.1109/TPS.2013.2274154. [15] HUANG X B, ZHOU S T, DAN J K, et al. Preliminary experimental results of tungsten wire-array Z-pinches on primary test stand [J]. Physics of Plasmas, 2015, 22(7): 072707. DOI: 10.1063/1.4926532. [16] HUANG X B, REN X D, DAN J K, et al. Radiation characteristics and implosion dynamics of Z-pinch dynamic hohlraums performed on PTS facility [J]. Physics of Plasmas, 2017, 24(9): 092704. DOI: 10.1063/1.4998619. [17] LI Z C, JIANG X H, LIU S Y, et al. A novel flat-response x-ray detector in the photon energy range of 0.1–4 keV [J]. Review of Scientific Instruments, 2010, 81(7): 073504. DOI: 10.1063/1.3460269. [18] STRAND O T, GOOSMAN D R, MARTIMESEZ C, et al. Compact system for high-speed velocimetry using heterodyne techniques [J]. Review of Scientific instruments, 2006, 77(8): 083108. DOI: 10.1063/1.2336749. [19] JENSEN B J, HOLTKAMP D B, RIGG P A, et al. Accuracy limits and window corrections for photon Doppler velocimetry [J]. Journal of Applied Physics, 2007, 101(1): 013523. DOI: 10.1063/1.2407290. [20] 李建中, 王德田, 刘俊, 等. 多点光子多普勒测速仪及其在爆轰物理领域的应用 [J]. 红外与激光工程, 2016, 45(4): 0422001. DOI: 10.3788/IRLA201645.0422001.LI J Z, WANG D T, LIU J, et al. Multi-channel photonic Doppler velocimetry and its application in the field of explosion physics [J]. Infrared and Laser Engineering, 2016, 45(4): 0422001. DOI: 10.3788/IRLA201645.0422001. [21] 经福谦. 实验物态方程导引 [M]. 2版. 北京: 科学出版社, 1999: 90–91. [22] 王昆仑, 任晓东, 黄显宾, 等. 用于“聚龙一号”上软X光通量探测的平响应X光二极管 [J]. 强激光与粒子束, 2016, 28(4): 045009. DOI: 10.11884/HPLPB201628.045009.WANG K L, REN X D, HUANG X B, et al. Flat spectral response XRD for diagnosing soft X-ray flux on PTS [J]. High Power Laser and Particle Beams, 2016, 28(4): 045009. DOI: 10.11884/HPLPB201628.045009. -
