摘要:
钢筋混凝土(RC)框架结构是大量政治经济活动的载体,然而全球爆炸袭击与公共安全事故频发,以及国际形势复杂多变,使得RC框架结构成为重要的打击与防护目标。为探究多次爆炸作用下RC框架结构的毁伤效应,设计并建造了一栋两层含填充墙的原型RC框架结构,分别开展了等效TNT当量为11.573kg和20kg的四发结构外爆炸和内爆炸试验,考察了不同位置和当量炸药爆炸作用下的冲击波载荷特征以及单个构件、房间和整体结构的动态响应和破坏模式。结果表明:近距离外爆炸作用下,楼板和填充墙可以有效衰减传播至房间内部的冲击波载荷,峰值超压降幅约84.75%。楼板和填充墙呈局部冲切破坏,房间内部构件和整体结构损伤相对较小;内爆炸作用下,楼板和填充墙呈整体冲切破坏,毁伤等级高于框架柱和梁。除冲击波载荷外,爆源房间墙板碎片的抛掷碰撞是造成沿冲击波传播方向填充墙和楼板损伤破坏的关键毁伤元。最后,基于建筑结构毁伤评估准则,对每发试验后单个构件、房间及整体结构的毁伤等级进行确定,得出内爆炸作用下建筑结构的毁伤等级和范围高于外爆炸工况。
Abstract:
Reinforced Concrete (RC) frame structures play a key role in numerous political and economic activities. However, the increasing frequency of explosion attacks and public safety incidents, coupled with the complex international situation, has rendered RC frame structures as crucial targets for both attack and protection. To investigate the damage effects of multiple explosions on RC frame structures, a full-scale two-story RC frame structure with masonry walls was designed and constructed. Based on this building, external and internal explosion tests were conducted under different TNT equivalents (11.573kg and 20kg). The load characteristics of shock waves, dynamic response and failure modes of structural components were examined. The results show that under close-range external explosion, the floor slabs and masonry walls can attenuate the shock wave loads propagated into the adjacent room, with a peak overpressure reduction of 84.75%. The floor slabs and masonry walls exhibit local shear failure, while the damage to the internal components and the global structure is minor. In contrast, under internal explosion, the floor slabs and masonry walls show global shear failure, with higher damage compared to the RC columns and beams. In addition to the shock wave loads, the explosive ejection of wall/slab fragments from the explosion source room is the primary reason for damage to the masonry walls and slabs along the direction of shock wave propagation. Finally, based on damage assessment criteria, the damage levels of components, rooms, and the RC structure for each test were determined. The damage level and range of RC structure under internal explosion is significantly higher than that under external explosion loads.
