Effects of external turbulence intensity on ethylene explosion characteristics
-
摘要: 本研究旨在阐明外加湍流对乙烯-空气爆炸特性的影响。在配备风扇生成湍流系统、高速纹影成像和压力采集装置的定容燃烧弹中开展实验,系统研究了湍流强度(u′=0.00~0.60 m/s)和当量比(Φ=0.6~2.0)对火焰形态、传播速度、爆炸超压和压力上升速率的影响。结果表明:增大湍流强度促进火焰表面褶皱并加速火焰传播,在u′=0.44~0.60 m/s时增强效应最为显著;归一化湍流火焰传播速度随湍流雷诺数增大呈现自相似行为,基于Ka数和Da数的关联式可准确描述火焰加速过程,R2均高于0.91。此外,较高的湍流强度通过改善燃料-空气混合和降低热损失,提高了最大爆炸超压和压力上升速率。进一步构建了融合初始条件、峰值和平滑性约束的物理引导神经网络模型用于预测超压演化,与XGBoost模型相比,其物理一致性和预测精度均得到提升。上述研究结果为湍流增强的乙烯爆炸危害提供了定量认识,并为乙烯相关工业过程的安全评估提供了支撑。
-
关键词:
Abstract: This study aims to clarify the influence of external turbulence on ethylene-air explosion characteristics. Experiments were performed in a constant-volume combustion chamber equipped with a fan-generated turbulence system, high-speed schlieren imaging, and pressure acquisition devices. The effects of turbulence intensity (u′ = 0.00-0.60 m/s) and equivalence ratio (Φ = 0.6-2.0) on flame morphology, propagation velocity, explosion overpressure, and pressure rise rate were systematically investigated. The results indicate that increasing turbulence intensity promotes flame surface wrinkling and accelerates flame propagation, with the most significant enhancement observed at u′ = 0.44-0.60 m/s. The normalized turbulent flame propagation velocity exhibits self-similar behavior with increasing turbulent Reynolds number, and Ka- and Da-based correlations accurately describe the acceleration process with R2 values above 0.91. Moreover, higher turbulence intensity increases the maximum explosion overpressure and pressure rise rate by enhancing fuel-air mixing and reducing heat loss. A physics-guided neural network model incorporating initial condition, peak, and smoothness constraints was further developed to predict overpressure evolution, achieving improved physical consistency and prediction accuracy compared with the XGBoost model. These findings provide quantitative insights into turbulence-enhanced ethylene explosion hazards and support safety assessment of ethylene-related industrial processes. -
